Modwright

Modwright LS 99

$6,500.00
Shipping calculated at checkout.
*Color: Black
 The Modwright LS99 is based on the LS 300 Reference balanced tube preamplifier, the LS 99 uses the same transformer coupled input and output topology, tube rectified, and SS regulated power supplies with (2) 6922 driver tubes. The power supply is outboard, but not dual mono, like the LS 300. In keeping with the `9' series of products, we took the best elements of our Reference design and built them into a more compact, simple, and elegant enclosure.

Pickup available at Shop location

Usually ready in 2-4 days

LS 99 Balanced Tube PreAmplifier


Design


The Modwright LS99 is based on the LS 300 Reference balanced tube preamplifier, the LS 99 uses the same transformer coupled input and output topology, tube rectified, and SS regulated power supplies with (2) 6922 driver tubes. The power supply is outboard, but not dual mono, like the LS 300. In keeping with the `9' series of products, we took the best elements of our Reference design and built them into a more compact, simple, and elegant enclosure. This allows 95% of the performance of the Reference product and reduces the price by nearly $5,000.

FEATURES

  • (2) XLR Fully Balanced Inputs.
  • (3) RCA Inputs.
  • (1) RCA HT/BP (Home Theater Bypass Input).
  • (2) XLR Fully Balanced Outputs.
  • (2) RCA Outputs.
  • Dual Remote 12V Trigger Outputs.
  • Remote Control: Volume, mute and trigger outputs.
  • Tube Output: 6922/6DJ8/7308/E88CC
  • Tube Rectified: 5AR4/GZ34 and Equivalents.
  • Pure Class A.
  • External Power Supply.

Reviews

SPECIFICATIONS

  • Gain: 11dB.
  • Frequency Response: 20Hz - 150Khz flat.
  • Input Impedance: 30K.
  • Output Impedance: 100 ohm.
  • Noise Floor: -110dB (unweighted).
  • Dimensions: Preamp = 10.5" W x 4.5" H x 12" D. (Depth includes 1.25" knobs and .75" RCA's. Height does not include exposed tubes. Overall height varies by tube mfr).
  • Dimensions: External Supply = 7" W x 9" D x 3"H
  • Weight: Preamp = 17 lbs. External Supply = 11 lbs.
  • Combined Shipping Weight: 33 lbs.
  • Umbilical: (1) 4 ft. umbilical with 8-pin Switchcraft connectors.
Proudly hand crafted in the U.S.A.
